INDUS BUCKET ELEVATOR

BACK

Indus Bucket Elevator Conveyor Belts are engineered to carry the material vertically.

Signiﬁcant heights and heavy elevator buckets require an extremely strong transverse belt construction. This type of construction is achieved by using our proprietary EP fabric reinforcement.
Transverse rigidity ensures ﬂat uniform surface for buckets to be ﬁxed on to the belt.
Minimum elongation helps in reduced down time.
Flexible enough to run on smaller pulley diameters in compact areas.
Compatible to ﬁx buckets of any material.
Facilitates even load distribution resulting in lower maintenance cost & increase in productivity.
Comes in a variety of cover properties to suit the material characteristic.

CEMENT

SAND

FOUNDERIES

Standard Widths	Up to 2200mm (86")
Type Of Fabric	Specially designed EP fabric
Breaker Fabric Ply	Optional / as per customer requirement
Standard Belt Rating	315 kN/m (170 PIW) to 3200 kN/m (914 PIW)
No. of Ply’s	2 Ply to 5 Ply
Rubber Cover Thickness	3mm (1/8") to 8mm (5/16")
Colour	Black
Cover Grades	Available in General Purpose Impact & Abrasion Resistant (M24, DIN-X,Y, HAR, SAR), Oil Resistant (OR), Heat Resistant(HR), Fire Resistant (FR) grades and combinations available on request.
Edge	Cut Edge / Moulded Edge
Splicing Method	Hot / Cold
Single Roll Length	Standard Length : 200 meters (656')
Standard Packing	Wrapping in HDPE sheets with Strapping
Belt Identification Number	A unique BIN (Belt Identication Number) At Every 10 Meters(33')

*Specifications are subject to change without notice.
